Project Description

HD-SDI / HDMI /DVI

HS-1C60TR

Syscom Korea, a leader in the market of pixel to pixel cabling solution,  created Fiber Optics. Syscom Korea cabling solution will be a perfect choice for overcoming the problems of facility access, capital cost, distance, EMI, ESD and bandwidth. Syscom Korea’s Optical HD-SDI Cable can send signals up to 20km without electrical or magnetic noises that plague performance of high speed HD-SDI.   Syscom Ko rea’s Optical HD-SDI solution consists of plug and play modules with HS-1C60T connecting to camera and HS-1C60R connecting to DVR side. The HS-1C60T receives, converts and sends out video data to fiber from the camera while HS-1C60R receives the optical signals, converts them back into video data and sends to DVR.

Data Sheet

Typical Set Up Diagram

Technical  Specification

  • Camera

    SD-SDI (SMPTE 259M / 344M)

    HD−SDI (SMPTE 292M)

    3G HD−SDI (SMPTE 424M)

  • Auto detect and Generate Pixel clock

  • No compression and lossless and transparent

  • transport

  • Locking DC power connector

  • Supports Pan/Tilt/Zoom

  • Supports RS232(all of baud-rate)

  • Supports Bidirectional audio data transfer

  • Status Monitoring LEDs ( PWR, ACT/Error )

  • Intelligent cable disconnect detecting ( Camera cable, Fiber cable )

  • Re-synchronization buttons

  • LC duplex fiber link (8-core fiber)

  • Allows remote operation up to 20km

  • Digital Voice communication

  • Medical Imaging

  • High precision security surveillance

  • Port/Harbor cargo container management

  • Intelligent Traffic Systems (ITS)

  • Border Control

  • Long haul image transmissions

  • Bridge inspection

  • Military & Defense Applications

  • Astronomy

  • Computer microscopy

  • Multi-media

Video input standard 1 CH
Resolution SMPTE 424M (1080p50/59.94/60)

SMPTE 292M (1080p25/30/60)

SMPTE 259M (720p25/30/50/60)
Wavelength 1310 / 1550 nm ( TX / RX )
Mode / Distance Single Mode / Max. 20 Km
Data Throughput 6.25 Gbps
Internal Audio input standard 24Bits Stereo / 8CH @ 48 KHz
External Audio input standard 24Bits Stereo @ 48 KHz
Microphone input standard @ 48 KHz
Function Equalizing, Re-clocking, Cable Driving
Indication LED Power / Operation (Green),

Optical Cable Disconnection (Red),

Camera Cable Disconnection (Orange)
RS485 Output PTZ, Terminal Block (One Touch)
RS232 Ports Supports all of Baud-rate
Power Input DC Jack (DC 12 / 24V)
Dimension 170 (W) x 130 (D) x 40 (H) mm
Power Consumption Max. 9.0 W
Connector Type LC

list_hs-1c60tr_1000
